Single-mode fiber categories and designations

optic fibers

Various international standards have their own designations for different types of single-mode fiber, which can be rather confusing. Below is a summary table that references the three main standards bodies in the governance of optical fiber specifications

  • IEC (International Electrotechnical Commission) is an international organization that sets standards for electrical, electronic, and related technologies. IEC standards are used by manufacturers, service providers, and governments around the world to ensure the safety, reliability, and interoperability of products and systems.
  • TIA (Telecommunications Industry Association) is a US-based organization that develops standards for telecommunications products and services. TIA standards are used to ensure the quality, performance, and compatibility of telecommunications equipment.
  • ITU (International Telecommunication Union) is a UN specialized agency that sets standards for telecommunications networks and services. ITU standards are used to ensure the global interoperability of telecommunications systems.



Description of fiber feature

ITU-T Recommendation

IEC 60793-2-50: 2018

IEC 60793-2-50: 2015

ANSI/TIA 492CAAC

Dispersion un-shifted single-mode optical fibers

G.652



G.652.B

B-652.B

B1.1

B-652.B

Dispersion un-shifted single-mode optical fibers with low water peak

G.652.D

B-652.D

B1.3

B-652.D

Dispersion shifted single-mode optical fibers

G.653



G.653.A

B-653.A

B2_a

B-653.A

G.653.B

B-653.B

B2_b

B-653.B

Cut-off shifted single-mode optical fibers

G.654



G.654.A

B-654.A

B1.2_a

B-654.A

G.654.B

B-654.B

B1.2_b

B-654.B

G.654.C

B-654.C

B1.2_c

B-654.C

G.654.D

B-654.D



B-654.D

G.654.E

B-654.E



B-654.E

Non-zero dispersion shifted single-mode optical fibers

G.655



B4



G.655.C

B-655.C

B4_c

B-655.C

G.655.D

B-655.D

B4_d

B-655.D

G.655.E

B-655.E

B4_e

B-655.E

Wideband non-zero dispersion shifted single-mode optical fibers

G.656

B-656

B5

B-656

Bending loss insensitive single-mode optical fibers

G.657



B6



G.657.A1

B-657.A1

B6_a1

B-657.A1

G.657.A2

B-657.A2

B6_a2

B-657.A2

G.657.B2

B-657.B2

B6_b2

B-657.B2

G.657.B3

B-657.B3

B6_b3

B-657.B3
